144-HUU803-90-00(J) for LEO Pump
The mechanical seal adopts a double-end face, multiple springs, and unbalanced cartridge structure. The axial dimensions are compact, the end face load is uniform, the rotation direction is not limited, and the installation is convenient and reliable. The flushing scheme can adopt PLAN 54.
Structure Features :
The mechanical seal adopts a double-end face, multiple springs, and unbalanced cartridge structure. The axial dimensions are compact, the end face load is uniform, the rotation direction is not limited, and the installation is convenient and reliable. The flushing scheme can adopt PLAN 54.
Operating Range:
Mediums: Suitable for transporting flammable, explosive, toxic and hazardous dangerous media.
Pressure: ≤1.6Mpa
Temperature: -40℃~220℃
Linear Speed: ≤20m/s
| Model | d1 | d2 | d3 | d4 | d5 | d6 | d7 | L1 | L2 | L3 | L4 | L5 | L6 | L7 | L8 | L9 | L10 | N | M |
| LK30 | 20 | 25 | 44 | 50 | 60 | - | 100 | 110 | 20 | 45 | 65 | 38 | 17 | - | 12 | 6 | 21.8 | 2 | 13.5 |
| LK40 | 30 | 35 | 56 | 63 | 74 | - | 115 | 124 | 20 | 48 | 68 | 48.5 | 25 | - | 23.5 | 8 | 33.3 | 2 | 13.5 |
| LK50 | 40 | 45 | 67 | 75 | 90 | - | 135 | 115 | 20 | 48 | 68 | 40 | 25 | - | - | 10 | 42.8 | 2 | 18.5 |
| LK50B | 40 | 45 | 67 | 75 | - | 110 | 150 | 115 | 20 | 53 | 78 | 39 | 23 | 5 | 17 | 10 | 42.8 | 4 | 13.5 |
| LK60 | 48 | 50 | 77 | 85 | - | 120 | 160 | 139 | 20 | 77.5 | 97.5 | 38 | 16 | 4 | - | 10 | 50.8 | 4 | 13.5 |
| LK70 | 60 | 68 | 95 | 105 | - | 145 | 180 | 130 | 30 | 59.3 | 89.3 | 35.5 | 17 | 4 | - | 12 | 62.8 | 4 | 18 |
| LK85 | 75 | 82 | 115 | 125 | - | 160 | 190 | 140.5 | 30 | 62 | 92 | 46.5 | 19 | 5 | - | 16 | 78.3 | 4 | 22 |
A: We deliver customized sealing solutions to diverse industrial sectors,including:
·Oil and Gas
·Refining
·Chemical and Petrochemical
·Water and Wastewater Treatment
·Pharmaceutical
·Power Generation
·Marine
Our products are designed to perform reliably in demanding environments across multiple industries.
A: HQ Seals provides custom sealing solutions customized for your working conditions. We manufacture seals according to:
· Technical drawings
· Physical samples
· Special material & performance specifications
· Non-standard sizes
We maintain close communication with clients to guarantee all finished products satisfy operational and environmental requirements.
A: First, identify the optimal configuration (single or double seal) according to the process fluid. Then verify operating parameters — pressure, temperature and shaft speed — to select the appropriate seal type and materials. Lastly, confirm available installation dimensions, and opt for either a component or cartridge seal subject to customer requirements and relevant standards. Seal selection is normally carried out by qualified technicians.
A: For mechanical seals that have been stored for a long period: we can grind the rotating and stationary rings, replace secondary sealing O-rings, conduct air tightness testing and issue the pressure test report.
We can provide on-site installation guidance service. For failed mechanical seals, we are able to deliver failure analysis reports.
A: Yes, repairs are available. Depending on the damage condition of the mechanical seal, we classify the overhaul into Level 1, Level 2 and Level 3 repair.
